The software, hardware, and structure of the QuicRun WP Mini24 are tailor-made for small-scale crawling vehicles. It has a large torque at low-speed and operates smoothly. The QuicRun WP Mini24 is the ideal choice for crawling vehicles for 1/16th, 1/18th, and 1/24th scale models.
Adjust drag brake force in real time:
The ESC programming port has an AUX function. Connect the signal cable (standard 2-pin cable) to an open channel on the receiver to adjust the drag brake force in real-time. Adjusting drag brake force on the fly can be achieved to meet various application environments.
All-weather operation capability:
The ESC's protection level reaches IP67. Able to easily cope with various competition environments such as rain, dust, and sand with its excellent waterproof and dust-proof protection.
Note: The above-mentioned IP67 protection level is splash-proof, water-resistant, and dust-proof under normal use. It is not permanently effective, and the protective performance may decrease due to daily wear and aging. Do not soak in water for a long time, otherwise the product may be damaged.
Built-in BEC supported for high-voltage servo:
The powerful switch mode BEC has a maximum current of 6A. The output voltage is switchable between 6V/7.4V and is suitable for various standard/high-voltage servos on the market.
Waterproofing switch:
The QuicRun WP Mini24 has a built-in waterproof switch with waterproof, dustproof, and impact-resistant. Completely solved the traditional mechanical switch in dusty, humid, and other harsh environments frequent jamming, contact corrosion, impact (such as falling to the ground) and lead to the mechanical switch automatically shut down and other problems.
Easy to install:
The QuicRun WP Mini24 uses a PH 2.0-3PIN female connector. Plug and play with HW motors or another brand of motors with the same plug. The input end uses a PH 2.0-2PIN female connector. Other models such as SCX24 can plug and play. The common connector saves the trouble of re-soldering plugs.
Note: In addition, the ESC comes standard with a brushed adapter cable for easy operation.
Support brushed and brushless modes:
The QuicRun WP Mini24 supports both brushed and brushless motors with great compatibility.
Note: The factory default is the brushless mode. If you are connecting to a brushed motor, please connect the A/C line and set the ESC to "Brushed Motor", otherwise the ESC may be damaged.
Support various LED/LCD programming boxes:
The ESC not only supports simple LED programming boxes but also supports high-end products like LCD programming boxes with a more complete display.
A vast variety of parameters:
The QuicRun WP Mini24 has a vast variety of parameters for adjustment. A total of 13 adjustable parameters are available. It includes commonly used parameters such as drag brake force and drag brake acceleration. It can adjust accurately the power requirements to meet various application setting needs.
Specifications:
Scale: 1/24th, 1/18th, 1/16th
Brushed/Brushless: Brushless, Brushed
Brushless/Brushed: Sensorless
Waterproof: Waterproof
Relevant Parameters:
Cont./Peak Current: 25A/60A
Input Voltage: 2-3S Lipo
BEC BEC Output: 6V/7.4V adjustable, continuous current 2A (Switch mode)
The software, hardware, and structure of the QuicRun WP Mini24 are tailor-made for small-scale crawling vehicles. It has a large torque at low-speed and operates smoothly. The QuicRun WP Mini24 is the ideal choice for crawling vehicles for 1/16th, 1/18th, and 1/24th scale models.
Adjust drag brake force in real time:
The ESC programming port has an AUX function. Connect the signal cable (standard 2-pin cable) to an open channel on the receiver to adjust the drag brake force in real-time. Adjusting drag brake force on the fly can be achieved to meet various application environments.
All-weather operation capability:
The ESC's protection level reaches IP67. Able to easily cope with various competition environments such as rain, dust, and sand with its excellent waterproof and dust-proof protection.
Note: The above-mentioned IP67 protection level is splash-proof, water-resistant, and dust-proof under normal use. It is not permanently effective, and the protective performance may decrease due to daily wear and aging. Do not soak in water for a long time, otherwise the product may be damaged.
Built-in BEC supported for high-voltage servo:
The powerful switch mode BEC has a maximum current of 6A. The output voltage is switchable between 6V/7.4V and is suitable for various standard/high-voltage servos on the market.
Waterproofing switch:
The QuicRun WP Mini24 has a built-in waterproof switch with waterproof, dustproof, and impact-resistant. Completely solved the traditional mechanical switch in dusty, humid, and other harsh environments frequent jamming, contact corrosion, impact (such as falling to the ground) and lead to the mechanical switch automatically shut down and other problems.
Easy to install:
The QuicRun WP Mini24 uses a PH 2.0-3PIN female connector. Plug and play with HW motors or another brand of motors with the same plug. The input end uses a PH 2.0-2PIN female connector. Other models such as SCX24 can plug and play. The common connector saves the trouble of re-soldering plugs.
Note: In addition, the ESC comes standard with a brushed adapter cable for easy operation.
Support brushed and brushless modes:
The QuicRun WP Mini24 supports both brushed and brushless motors with great compatibility.
Note: The factory default is the brushless mode. If you are connecting to a brushed motor, please connect the A/C line and set the ESC to "Brushed Motor", otherwise the ESC may be damaged.
Support various LED/LCD programming boxes:
The ESC not only supports simple LED programming boxes but also supports high-end products like LCD programming boxes with a more complete display.
A vast variety of parameters:
The QuicRun WP Mini24 has a vast variety of parameters for adjustment. A total of 13 adjustable parameters are available. It includes commonly used parameters such as drag brake force and drag brake acceleration. It can adjust accurately the power requirements to meet various application setting needs.
Specifications:
Scale: 1/24th, 1/18th, 1/16th
Brushed/Brushless: Brushless, Brushed
Brushless/Brushed: Sensorless
Waterproof: Waterproof
Relevant Parameters:
Cont./Peak Current: 25A/60A
Input Voltage: 2-3S Lipo
BEC BEC Output: 6V/7.4V adjustable, continuous current 2A (Switch mode)
