 Hobbywing XERUN XR10 STOCK SPEC G2 Brushless ESC
All
Prev
Next
Showing #9657 of All Parts


LOADING IMAGES

Request Additional Photos
Innovation Powered By Passion
PART: #HW/30112402
This item ships Free WORLDWIDE. Details
OUR INVENTORY:
In Stock and Ready To Ship!
USD $126.99
Best Price Guarantee

Add To Cart
Shipping Options

Request a Video Intro
CUSTOMER REVIEWS

This product currently has 0 reviews

Currently all feedbacks are left by AsiaTees customers.

TAGGED CATEGORIES:
ESC (Brushless)
PRODUCT INFORMATION:
  • Features:
    • Built-in reverse voltage protection
    • Higher power, lower temperature
    • Built-in BEC supporting high-voltage servos
    • Optimized cable outlet for convenient wiring
    • Low center of gravity, easy to balance
    • Real-time data acquisition, easy analysis
    • Multi-level throttle and brake curvature, freely adjustable
    • Drag brake frequency is independently adjustable.
    • RPM limit function
    • Dual firmware, multiple applications

    Type:
    • Scale: 1/10th
    • Brushed/Brushless: BL
    • Sensored/Sensorless: SD
    • Waterproof: No

    Specifications:
    • Cont./Peak Current: 100A/500A
    • Input Voltage: 2S Lipo
    • BEC Output: Switch Mode 6V/7.4V @5A

    Wires & Connectors:
    • Input Wires: Black-13AWG-200MMmm*2
    • Output Wires: Black-13AWG-200MMmm*3
    • Input Connectors: No
    • Output Connectors: No

    Fan:
    • Size: 20*20*8mm
    • Voltage Range: 5-7.4V
    • Powered by: BEC

    ESC Programing via:
    • SET Button on ESC: Not Supported
    • LED Program Box: Not Supported
    • LCD G2 Program Box: Supported
    • LCD PRO: Supported
    • OTA Programmer: Supported
    • Program Port: Separate Program Port

    Data Recording:
    • Extreme value: Supported
    • Real-time Data: Supported
    • Historical data (Graph): Supported

    Firmware:
    • Firmware Upgrade: Supported

    Size & Weight:
    • Size: 34.8*30*13.8mm
    • Weight: 63g(w/Wires)

    Applications:
    • Motors: 3650 size motors
    • Vehicles: Stock Class of 1/10th Touring Car and Buggy Racing, 1/10th Drift
    • KV Rating/T Count: ≥10.5T
  • Package total weight: 139.00 grams (incl. packaging)
  • Package size: 9.00 x 12.50 x 7.00cm
  • Factory description: Hobbywing XERUN XR10 STOCK SPEC G2 Brushless ESC
  • Manufactured by Hobbywing
  • Manufacturer number: HW/30112402
  • This item is eligible for in-store promotions
  • Nobody beats our price! See our Best Price Guarantee, or your money back!
  • Questions about this product? Ask Our Technical Support
  • You may Request Additional Product Information for this product.
  • Looking for screws / bolts to assemble this product? Email Us
View ATees.com Glossary of Terms

Find something wrong in this description?
Help us fix it! Report An Error

XERUN XR10 STOCK SPEC G2 Brushless ESC by Hobbywing


LOADING IMAGES

Part: #HW/30112402
*Ships Free WORLDWIDE
USD $126.99

Add To Cart
In Stock and Ready To Ship!
Tagged Categories
ESC (Brushless)
  • Features:
    • Built-in reverse voltage protection
    • Higher power, lower temperature
    • Built-in BEC supporting high-voltage servos
    • Optimized cable outlet for convenient wiring
    • Low center of gravity, easy to balance
    • Real-time data acquisition, easy analysis
    • Multi-level throttle and brake curvature, freely adjustable
    • Drag brake frequency is independently adjustable.
    • RPM limit function
    • Dual firmware, multiple applications

    Type:
    • Scale: 1/10th
    • Brushed/Brushless: BL
    • Sensored/Sensorless: SD
    • Waterproof: No

    Specifications:
    • Cont./Peak Current: 100A/500A
    • Input Voltage: 2S Lipo
    • BEC Output: Switch Mode 6V/7.4V @5A

    Wires & Connectors:
    • Input Wires: Black-13AWG-200MMmm*2
    • Output Wires: Black-13AWG-200MMmm*3
    • Input Connectors: No
    • Output Connectors: No

    Fan:
    • Size: 20*20*8mm
    • Voltage Range: 5-7.4V
    • Powered by: BEC

    ESC Programing via:
    • SET Button on ESC: Not Supported
    • LED Program Box: Not Supported
    • LCD G2 Program Box: Supported
    • LCD PRO: Supported
    • OTA Programmer: Supported
    • Program Port: Separate Program Port

    Data Recording:
    • Extreme value: Supported
    • Real-time Data: Supported
    • Historical data (Graph): Supported

    Firmware:
    • Firmware Upgrade: Supported

    Size & Weight:
    • Size: 34.8*30*13.8mm
    • Weight: 63g(w/Wires)

    Applications:
    • Motors: 3650 size motors
    • Vehicles: Stock Class of 1/10th Touring Car and Buggy Racing, 1/10th Drift
    • KV Rating/T Count: ≥10.5T
  • Product weight: 139.00 grams
  • Package size: 9.00 x 12.50 x 7.00cm
  • Factory description: Hobbywing XERUN XR10 STOCK SPEC G2 Brushless ESC
  • Manufactured by Hobbywing
  • Manufacturer number: HW/30112402
  • This item is eligible for in-store promotions
  • Nobody beats our price! See our Best Price Guarantee, or your money back!
  • Questions about this product? Ask Our Technical Support
  • You may Request Additional Product Information for this product.
  • Looking for screws / bolts to assemble this product? Email Us
View ATees.com Glossary of Terms
Find something wrong in this description?
Help us fix it! Report An Error
