• Innovative intelligent freewheeling technology, high efficiency, and low-temperature rise

The innovative intelligent freewheeling technology enables the ESC to have higher driving efficiency and lower operating temperature. The stability and reliability of the ESC is improved.

• Upgrade BEC

The BEC has been upgraded from the previous generation from 6V/3A to 6V/7.4V and is fully adjustable. It is equipped with a continuous current of 6A, and up to a maximum current of 12A. It supports most high-voltage servos on the market.

• Exceptional protection and operation

Equipped with excellent waterproofing and dustproofing performance to cope with various climatic conditions and harsh environments. The protection level of the ESC reaches IP67.

Note: The IP67 protection level mentioned above is splash-proof, water-proof, and dust-proof under normal use, but it is not permanently effective, and the protection performance may decline due to daily wear and aging. Do not soak in water for a long time, otherwise, the product may be damaged.

• Efficient cooling system

The internal power board of the ESC is covered with a patented copper heat conduction bus bar to help facilitate the rapid conduction of internal heat to the radiator. Additionally, a fan is added to dissipate heat. These constitute to a highly reliable cooling system to ensure that the ESC is always at a safe operating temperature.

• Durable electronic switch

The upgraded electronic power switch solves the corrosion and impact damage that occurs frequently in traditional mechanical switches in dusty and humid environments. Accidental shutdowns are no longer an issue.

The lifespan of the switch is 50000times longer, waterproof, dustproof, impact-resistant

• Capacitor overheating protection function

Capacitor overheating protection features can effectively prevent exploding customers due to overload usage. This helps to eliminate damage to the ESC.

• Super large built-in capacitor

The built-in capacitor capacity of the ESC is as high as 2040 uF and eliminates the need for external capacitors.

• Scale:1/8^th
• Brushed/Brushless: Brushless
• Sensored/Sensorless: Sensorless
• Waterproof: Waterproof
• /Peak Current: 150A/950A
• Input Voltage: 3-6S Lipo
• BEC Output: Switch Mode 6V/7.4V @6A
• Wires & Connectors:
  • Input Wires: Black-10AWG-150MM / Red-10AWG-150MM
  • Output Connectors: 6.5mm Gold (female)
• ESC Programing via
  • SET Button on ESC: Not Supported
  • LED Program Box: Supported
  • LCD G2 Program Box: Supported
  • OTA Programmer: Not Supported
  • Program Port: Separate Program Port
• Firmware Upgrade: Not Supported
• Size & Weight
  • Size: 60*48*40.4mm
  • Weight: 169.5g(Included wires)
• Applications:
  • Motors: Sensorless / Sensored Brushless Motor (only in sensorless mode)
  • Vehicles: 1/8^th Truck, Monster truck
  • KV Rating/T Count:
    • With 4S Lipo: KV ≤ 3000
    • With 6S Lipo: KV ≤ 2400 4274 size motor
