This is a complete assembled BRX90 Pass-Thru PHAT Axle for 6x6 and 8x8 builds. The Boom Racing PHAT axle is the go-to scale truck axle combining high-performance features with precision-made scale realism. It is an ultra-scale, heavy-duty axle set designed for top performance for any truck builds. The beefy housing keeps the vehicle nicely planted on the ground.
Features:
High mass heavy-duty performance axle for crawler and truck projects
Straightforward solid-axle design for easy installation
New keyed HD helical bevel gear set specifically designed for the pass-thru axle. Bevel gears are keyed for extra durability and strength.
Reversible axle bevel gear positions for standard or counter rotation setups (swap gear to the opposite side for counter rotation center drivetrain setup)
Detachable CNC aluminum truss
Leaf spring ready for over or under the axle leaf spring setup
BADASS HD Steel wheel shaft for ultimate durability and strength for the axle drivetrain
12.9-grade hardware
Full ball bearings
Specs:
Weight: 200.1 grams (fully assembled)
176mm / 6.93 inch pin to pin (front and rear)
Ring Gear: 30T
Pinion Gear: 8T
Includes:
1x BRX90 Pass-Thru PHAT Axle
2x 12mm alum hex
2x M4 wheel nut
2x drive pin
2x set screw
You will need:
6X6 Axle Gear Set for BRX70/BRX80/BRX90 PHAT Axle for the connecting axle #BRX026615KIT
Optional:
For Leaf Spring setup, additional optional parts may/may not be needed depending on your setup. Leafs can be mounted directly on top or under the axle. We recommend
Steel Leaf Spring Channel w/ Shock Mount for BRX70 / BRX80 / BRX90 Axle (2) BRLC7010
When you receive the axle: Make sure all of the screws are tightened properly.
The gear positions are factory setup and should be ready to go. Rotate the drivetrain by hand for physical inspection.
Install spacers accordingly between the center driveshaft and the input shaft to prevent the input shaft from unnecessary slop.
Package total weight: 262.00 grams (incl. packaging)
Package size: 8.50 x 23.50 x 7.00cm
Factory description: Boom Racing BRX02 Complete Assembled BRX90 Pass-throughy Axle
This is a complete assembled BRX90 Pass-Thru PHAT Axle for 6x6 and 8x8 builds. The Boom Racing PHAT axle is the go-to scale truck axle combining high-performance features with precision-made scale realism. It is an ultra-scale, heavy-duty axle set designed for top performance for any truck builds. The beefy housing keeps the vehicle nicely planted on the ground.
Features:
High mass heavy-duty performance axle for crawler and truck projects
Straightforward solid-axle design for easy installation
New keyed HD helical bevel gear set specifically designed for the pass-thru axle. Bevel gears are keyed for extra durability and strength.
Reversible axle bevel gear positions for standard or counter rotation setups (swap gear to the opposite side for counter rotation center drivetrain setup)
Detachable CNC aluminum truss
Leaf spring ready for over or under the axle leaf spring setup
BADASS HD Steel wheel shaft for ultimate durability and strength for the axle drivetrain
12.9-grade hardware
Full ball bearings
Specs:
Weight: 200.1 grams (fully assembled)
176mm / 6.93 inch pin to pin (front and rear)
Ring Gear: 30T
Pinion Gear: 8T
Includes:
1x BRX90 Pass-Thru PHAT Axle
2x 12mm alum hex
2x M4 wheel nut
2x drive pin
2x set screw
You will need:
6X6 Axle Gear Set for BRX70/BRX80/BRX90 PHAT Axle for the connecting axle #BRX026615KIT
Optional:
For Leaf Spring setup, additional optional parts may/may not be needed depending on your setup. Leafs can be mounted directly on top or under the axle. We recommend
Steel Leaf Spring Channel w/ Shock Mount for BRX70 / BRX80 / BRX90 Axle (2) BRLC7010
When you receive the axle: Make sure all of the screws are tightened properly.
The gear positions are factory setup and should be ready to go. Rotate the drivetrain by hand for physical inspection.
Install spacers accordingly between the center driveshaft and the input shaft to prevent the input shaft from unnecessary slop.
Product weight: 262.00 grams
Package size: 8.50 x 23.50 x 7.00cm
Factory description: Boom Racing Boom Racing BRX02 Complete Assembled BRX90 Pass-throughy Axle
