Keep improving to pursue perfect, from V10 G3 to V10 G3R
Features:
Build extreme performance for competition.
The Hobbywing's R&D Department cooperated closely with Jan Ratheisky, Max Mächler, and other international famous drivers to research and development as well as test continuously. After hundreds of improvements and adjustments, the performance was made to the highest level for competition. it has been proven to be very successful in some big race events. It won second place in the 1/10 touring car Stock Group, and both the first place and second place in the F1 Group of European Championship(EFRA). G3R JMRCA motor also won the first place and third place in the Stock 13.5T project of the Japanese National Championship
Improved Power & RPM
The optimized stator structure combined with the super magnetic rotor improves the G3R Stock motor’s torque by 13.3%, KV value by 6.5%, and maximum output power by 8.6% when compared to the V10 G3 Stock motor. The high torque, RPM and power make it a “secret weapon” for the Stock class racing
Low Resistance but High Efficiency
Its resistance is reduced by 11% but the efficiency is improved by 6% when compared to the V10 G3 Stock motor. The super high significantly slow down the temperature increase.
Super Lightweight
The G3R Stock weighs only 139g and is 8.6% lighter than some popular Stock motors (that weigh 152g) on the market. The light-weight motor allows drivers to easily control the balance of their RC vehicle
Great Heat Dissipation
The special shell design which makes the stator core (/laminations) expose to the air will maximize cooling, the big holes on the front & rear end plates will guarantee outstanding heat dissipation.
Re-buildable Structure
The detachable structure design for regular cleaning & maintenance will effectively prolong the service life of the motor and retain its efficiency.
Stock & Optional Rotors
The stock super magnetic rotor (PN 30820411?7-12.5*25.2-G*S) for 13.5T~21.5T G3R Stock motors is applicable to the Blinky mode of Stock class racing, while the optional rotor (PN 30820416?7-12.2*24.1-D*S) is appliable to the Super Stock class (Boost & Turbo timings can be activated) racing. With these rotors, the G3R motor will be applicable to two kinds of Stock class racing.
High-quality Components
The use of high-performance stator core (/laminations), heat(200ºC)-resistant pure copper wire, heat(180ºC)-resistant rotor with strong structure, world-class high precision and high strength bearings, and copper solder tabs with super current endurance will guarantee excellent performance and great durability.
Specifications:
Scale: 1/10th
Brushed/Brushless: BL
Sensored/Sensorless: SD
Pole Count: 2
KV Rating: 1780
LiPo Cells:2-3S
No-load Current(A): 2.1
(mm): 35.9
Length (mm): 51.2
Shaft Diameter (mm): 3.17
Weight (g): 145
Front Bearing: D9*D4*t4
Rear Bearing: D9*D4*t4
Applications: 1/10th STOCK Class Racing & Rock Crawler
This item replaced these previous versions: HW/30401113
Color: Black
Package total weight: 201.00 grams (incl. packaging)
Factory description: Hobbywing XERUN 1/10th Sensored Brushless Motor V10 G3R 25.5T 1500KV Black
Keep improving to pursue perfect, from V10 G3 to V10 G3R
Features:
Build extreme performance for competition.
The Hobbywing's R&D Department cooperated closely with Jan Ratheisky, Max Mächler, and other international famous drivers to research and development as well as test continuously. After hundreds of improvements and adjustments, the performance was made to the highest level for competition. it has been proven to be very successful in some big race events. It won second place in the 1/10 touring car Stock Group, and both the first place and second place in the F1 Group of European Championship(EFRA). G3R JMRCA motor also won the first place and third place in the Stock 13.5T project of the Japanese National Championship
Improved Power & RPM
The optimized stator structure combined with the super magnetic rotor improves the G3R Stock motor’s torque by 13.3%, KV value by 6.5%, and maximum output power by 8.6% when compared to the V10 G3 Stock motor. The high torque, RPM and power make it a “secret weapon” for the Stock class racing
Low Resistance but High Efficiency
Its resistance is reduced by 11% but the efficiency is improved by 6% when compared to the V10 G3 Stock motor. The super high significantly slow down the temperature increase.
Super Lightweight
The G3R Stock weighs only 139g and is 8.6% lighter than some popular Stock motors (that weigh 152g) on the market. The light-weight motor allows drivers to easily control the balance of their RC vehicle
Great Heat Dissipation
The special shell design which makes the stator core (/laminations) expose to the air will maximize cooling, the big holes on the front & rear end plates will guarantee outstanding heat dissipation.
Re-buildable Structure
The detachable structure design for regular cleaning & maintenance will effectively prolong the service life of the motor and retain its efficiency.
Stock & Optional Rotors
The stock super magnetic rotor (PN 30820411?7-12.5*25.2-G*S) for 13.5T~21.5T G3R Stock motors is applicable to the Blinky mode of Stock class racing, while the optional rotor (PN 30820416?7-12.2*24.1-D*S) is appliable to the Super Stock class (Boost & Turbo timings can be activated) racing. With these rotors, the G3R motor will be applicable to two kinds of Stock class racing.
High-quality Components
The use of high-performance stator core (/laminations), heat(200ºC)-resistant pure copper wire, heat(180ºC)-resistant rotor with strong structure, world-class high precision and high strength bearings, and copper solder tabs with super current endurance will guarantee excellent performance and great durability.
Specifications:
Scale: 1/10th
Brushed/Brushless: BL
Sensored/Sensorless: SD
Pole Count: 2
KV Rating: 1780
LiPo Cells:2-3S
No-load Current(A): 2.1
(mm): 35.9
Length (mm): 51.2
Shaft Diameter (mm): 3.17
Weight (g): 145
Front Bearing: D9*D4*t4
Rear Bearing: D9*D4*t4
Applications: 1/10th STOCK Class Racing & Rock Crawler
Color: Black
Product weight: 201.00 grams
Factory description: Hobbywing XERUN 1/10th Sensored Brushless Motor V10 G3R 25.5T 1500KV Black
