 Scorpion Scorpion Vanguard S3-140 Modify Kit Set

 All

Your Quality Brushless Power System Provider
PART: #SCORPION/520
OUR INVENTORY:
Out Of Stock
USD $224.99
Best Price Guarantee


CUSTOMER REVIEWS

This product currently has 0 reviews

Currently all feedbacks are left by AsiaTees customers.

TAGGED CATEGORIES:
PRODUCT INFORMATION:
  • Specifications
  • Cont./ Brust Current *A | 140/800A
  • Supported Sensored and Sensorless Brushless Motor
  • Cars applicable | 1/8th & 1/10th on road and off road
  • Motor Limit | >= 4.5T
  • Resistance | 0.0004Ohm*2
  • Voltage Input | 1s-3s LiPo
  • BEC | 6V@3A DC-DC
  • Footprint | 30,6 mm (W) x 35,6 mm (L)
  • Size (w/o FAN) | 35.8 x 35.6 x 21.8 mm
  • Weight | 40g
  • FAN | 6V@0.2A
  • External Programming Port Output | 2
  • Burst current rating according to MOS FET specification

    Features

  • Build with military specification component.
  • Wide input voltage range 3-14V (1S-3S Lipo)
  • Sensored and Sensorless brushless motors (BLDC)
  • Drive down to 4.5T motor (Scorpion Vanguard S3-140)
  • High current, up to 140A continues current, with current protection. (Scorpion Vanguard S3-140 Modify Kit Set)
  • Factory driver suggested setting
  • Profession PC program
  • Logging, store up to 8,000 records of system parameters
  • Aluminum heat sink
  • Build-in temperature sensor with adjustable temperature protection.
  • True DC-DC 3 A/6V BEC for servo and receiver
  • Multiple protection
  • Adjustable Voltage control and protection(cutoff, motor stop) with LiPo AutoDetect mode.
  • Motor over temperature protection (for Scorpion RS-3420 motor)
  • 2 x hall sensor connectors, each can be used for PC connection either..
  • Flexible adjustment
  • Wide range of settings for different purpose and race course

  • Package total weight: 195.00 grams (incl. packaging)
  • Factory description: Scorpion Scorpion Vanguard S3-140 Modify Kit Set
  • Manufactured by Scorpion
  • Manufacturer number: SCORPION/520
  • This item is not eligible for in-store promotions
  • Nobody beats our price! See our Best Price Guarantee, or your money back!
  • Questions about this product? Ask Our Technical Support
  • You may Request Additional Product Information for this product.
  • Looking for screws / bolts to assemble this product? Email Us
