• Multi-Connection Formed Steel Crawler Chassis, new design frame can reduce the frame weight and ensure the strength of the crawler.
• Alloy Front and Rear Axles are strong and durable. The kingpin caster angle is 8°degree, Kingpin inclination angle is 8°degree.
• Cragsman takes full advantage of its excellent 45 degree steering angle to get better traction, you can easily clear the technical terrain obstacle.
• Remote Control Front and Rear Diff Locks. Cragsman makes you can lock and unlock the front and rear differentials to adjust your driving needs directly from your transmitter.
• Partition transmission system. Shift Between 2WD and 4WD easily, remote controlled by transmitter
• Remote control High/Low 2 speed transmission. Low speed gear ratio is 2.6, high speed gear ratio is 1.8.
• High simulated spare wheel carrier with full size of Wheel.
• 2inch wheel rim (PROCOMP authorized) and 5.3X2.2R2.2 super soft tires (Mark Ma authorized)
• Modular design makes disassembly and assembly easy.
• Traction Hobby design-THT6 Transmitter 6 channels
• Traction Hobby Customized HW-WP-860-DUAL-RTR 60A brush ESC
• RS550 37T Brushed Crawler Motor

Specification:

Power:

• Motor:RS550 37T Brushed Crawler Motor
• ESC:HW-WP-860-DUAL-RTR 60A brush ESC
• Battery:Support 7.4V 2S Lipo battery/7.4V Li-no battery/7.2V Ni-Mh battery(Not included)

Parameter:

• Scale: 1/8 Large Scale
• Car size: L-670mm*W-302mm*H-305.5mm
• Wheel base: 374mm Wheel track: 245mm
• Chassis underground clearance: 83mm
• Minimum underground clearance :45mmGross weight: 7.95KG
• Carton size: 706mm*378mm*284mm

Frame:

• Chassis frame:Multi-Connection design 2mm thickness formed steel
• Suspension :Full metal alloy front and rear straight axle/non independent
• Angle: Approach Angle: 63°/ Departure Angle: 41°/Passing Angle: 52°
• Shock Absorber:Metal adjustable hydraulic shock absorber with oil filling

Driving:

• Pinion gear:14T
• Spur gear:60T Nylon tooth
• Driving:4WD /2WD Shifting transmission system
• Wheel :2.2inch plastic rim (PROCOMP authorized) and 5.3X2.2R2.2 super soft tires (Mark Ma authorized)

Electronic equipment:

• Steering servo : 20KGS Degree/25T
• Front diff lock servo : 3KGS Degree/25T
• Rear diff lock servo : 3KGS Degree/25T
• Transfer box servo : 3KGS Degree/25T
• Two speed servo:3KGS Degree/25T
• Transmitter: Traction Hobby design-THT6 Transmitter 6 channels
